Redexim Verti-Drain 7212

Redexim Verti-Drain 7212

The Verti-Drain® 7212 is well suited to lower HP tractors, this very capable model for aeration to a depth of 25cm / 10” on the more sensitive of turf areas. The 7212 is particularly popular hard to reach areas due to its overall dimensions while maintaining all the features of larger Verti-Drains.

  • Compact yet capable
  • Low tractor HP requirment
  • Broad range of tine options
  • See the Verti-Drain® 7215 for a wider working width



Standard components

  • Solid Tine 12x250mm (1/2x10") 2381837 x 18
  • Toolbox with combi tool and manual x 1
  • PTO Shaft x 1




Deep-Tine Aeration with Verti-Drain

An aeration method uses solid tines to create deep holes into the turf without removing any soil. The Verti-Drain insert a tine that kicks to gently lift and shatter the soil in a uniform manner to further break up compaction and create space in the soil profile for air, water, and grass plant roots.

The world-renowned Verti-Drain aerator was invented by Redexim more than 40 years ago. It has changed the method of soil aeration across the world, becoming the ‘must use’ for turf managers in their battle to aid turf growth in challenging environments.



About Redexim

At Redexim, we believe in developing strong long-term relationships with our customers. Trust and respect are therefore core values, as well as our commitment to guarantee and live up to our value promise. It is our mission to not only meet customer expectations but to exceed them. This has made Redexim, a world leader in turf maintenance equipment.





Centaur Asia Pacific is the distributor for Redexim range of products in Hong Kong, Macau, and Malaysia (Johor).

Updated on: 18 March 2022

Specifications

SKU 7212
Working width (m) 1.2
Working width (inch) 48
Max. Working depth (mm) 250
Max. Working depth (inch) 10
Working speed at hole spacing 65 mm 1
Weight (kg) 483
Weight (lbs) 1062
Hole distance with 12 mm tines (mm) 65
Hole distance with 1 2 x 6 inch tines (inch) 2.5
Hole distance with 18 mm tines (mm) 100
Hole distance with 3 4 x 9 inch tines (inch) 4
Hole spacing distance driving direction (mm) 25 - 165
Hole spacing distance driving direction (inch) 1 - 6-1/2
Max diameter solid tine (mm) 18 x 250
Max diameter solid tine (inch) 3/4 x 10
Max diameter hollow tine (mm) 25 x 250
Max diameter hollow tine (inch) 1 x 10
Min. Tractor HP required 18
Min. lifting capacity (kg) 570
Min. lifting capacity (LBS) 1250
Max. capacity with spacing 65 mm (m² hr) 1200
Max. capacity with spacing 2-1 2 inch (ft² hr) 11000
Three-point hitch 3-point CAT 1
Rpm Max. 500
Gearbox oil 80W90 3 liter
Lubricant EP 2
Dimensions (width mm) 1350
Dimensions (height mm) 800
Dimensions (length mm) 1100
Dimensions (width inch) 44
Dimensions (height inch) 32
Dimensions (length inch) 54
Slip clutch setting 450 NM (3983 lbf-in)



Options

Description Quantity Article number
Windrow Kit for 72 Series 1 211.721.016
Core Collector 1 9100080
Turf Hold Down Kit for 12mm tines -7212 1 211.721.014
Turf Hold Down Kit for 18mm tines -7212 1 211.721.012
Solid Tine 5x125mm (3/16x5") - Requires Adapter 5mm tines (3/16") 314.205.043 x 18 18 311.105.125
Solid Tine 5x125mm (3/16x5") - Requires MTH Block for (21) tines 5mm (3/16") 314.425.170 x 6 126 311.105.125
Solid Tine 8x150mm (5/16x6") - Requires Adapter 8mm tines (5/16")314.208.043 x 18 18 311.108.150
Solid Tine 8x150mm (5/16x6") - Requires MTH Block for (6) tines 8mm (5/16") 9990206 x 6 36 311.108.150
Solid Tine 8x175mm (5/16x7") - Requires Adapter 8mm tines (5/16") 314.208.043 x 18 18 9990056
Solid Tine 8x175mm (5/16x7") - Requires MTH Block for (6) tines 8mm (5/16") 9990206 x 6 36 9990056
Solid Tine 8x250mm (5/16x10") - Requires Adapter 8mm tines (5/16") 314.208.043 x 18 18 9990059
Solid Tine 12x150mm (1/2x6") 18 311.112.150
Solid Tine 12x200mm (1/2x8") 18 311.112.200
Solid Tine 18x200mm (3/4x8") 12 311.118.200
Solid Tine 18x250mm (3/4x10") 12 2381841
Hollow Tine 10x6x80mm (3/8x1/4x3") - Requires Adapter 8mm tines (5/16") 314.208.043 x 18 18 311.210.080
Hollow Tine 10x6x80mm (3/8x1/4x3") - Requires MTH Block for (6) tines 8mm (5/16") 9990206 x 6 36 311.210.080
Hollow Tine 10x6x125mm (3/8x1/4 x 5") MD:8mm - Requires Adapter 8mm tines (5/16") 314.208.043 x 18 18 311.210.127
Hollow Tine 10x6x125mm (3/8x1/4 x 5") MD:8mm - Requires MTH Block for (6) tines 8mm (5/16") 9990206 x 6 36 311.210.127
Hollow Tine 16/10x150mm (5/8x3/8x6") MD:12mm 18 311.216.150
Hollow Tine 16/10x175mm (5/8x3/8x7") MD:12mm 18 9990022
Hollow Tine 19/12x150mm (5/8x3/8x6") MD:12mm 18 311.219.150
Hollow Tine 19/12x200mm (3/4x1/2x8") MD: 18mm 12 311.219.200
Hollow Tine 19/12x200mm (3/4x1/2x8")MD: 12mm 18 311.219.201
Hollow Tine 19/12x225mm (3/4x1/2x9") MD: 12mm 12 311.219.225
Hollow Tine 19/12x225mm (3/4x1/2x9") MD:12mm 18 311.219.226
Hollow Tine 19/12x250mm (3/4x1/2x10") MD:18mm 12 9990023
Hollow Tine 19/12x250mm (3/4x1/2x10") MD:12mm 18 9990040
Hollow Tine 25/16x200mm (1x5/8x10") MD: 18mm 12 311.225.200
Hollow Tine 25/16x225mm (1x5/8x9") MD:18mm 12 311.225.225
Hollow Tine 25/17x250mm (1x5/8x10") MD: 18mm 12 9990024
Cross Tine 12x90mm (1/2x3 1/2") MD: 8mm - Requires Adapter 8mm tines (5/16") 314.208.043 x 18 18 9990020
Cross Tine 12x90mm (1/2x3 1/2") MD: 8mm - Requires MTH Block for (6) tines 8mm (5/16") 9990206 x 6 36 9990020
Cross Tine 12x90mm (1/2x3 1/2") MD:12mm 18 311.812.090
Cross Tine 19x120mm (3/4x5") MD:12mm 18 9990021
Chisel Tine 4.8x19x175mm (3/16x3/4x7") MD:12mm 18 311.619.175
Chisel Tine 4.8x19x120mm (3/16x3/4x4 3/4") MD:12mm 18 311.619.120
